Mean Well – 60W SINGLE OUTPUT WITH BAT/CHARG, UPS

Mean Well – 60W SINGLE OUTPUT WITH BAT/CHARG, UPS

Mean Well DRC-60A single output DIN rail power supply with battery charger (UPS function) MW-DRC-60A
Key Features

Input Voltage: 90–264VAC (47–63Hz) or 127–370VDC
Output Voltage: 13.8VDC
Output Current: Up to 4.3A
Power Rating: 59.3W
Dual output channels for load and battery charging
Fanless design, cooled by free air convection
Alarm signals for AC OK and battery low via relay contact
LED indicator for power on
Protections: short circuit, overload, over voltage, battery low cut-off, and battery reverse polarity (by fuse)
Operating temperature: -30°C to +70°C
DIN rail mountable (TS35/7.5 or 15)

MW-DRC-60A

DRC-60A
